Wall Mounted Pergola Kit with Shade Sail for 140x140 Timber Posts

Bracket Features Precision Crafted for 90x90mm Timber Fit (No Shaving)
Weather-resistant & rust protective coating
Laser-cut, folded and internally welded for premium quality finish
10-year limited warranty on steel brackets

4 x Base Brackets: 2 Brackets to mount 140x140mm timber posts to a wall and 2 to anchor vertical posts securely to solid base (e.g. concrete or decking).

2 x Corner Brackets to connect 140x140mm posts and create a sturdy frame.

1 x Shade Sail with several size options: 2.24x2.24m, 2.24x2.84m, 2.84x2.84m, 2.84x3.44m & 3.44x3.44m

Note: Shade Sail sizes designed to fit standard timber lengths available at your timber warehouse (e.g. 2.24x2.24m to fit 2.4x24m or 2.84x2.84m with 3x3m)

96 x 12g/38mm Black Plated Fastening Screws to securely fasten brackets to timber.

For instructions on how to install a Modaprax Pergola with Shade Sail, please access the Modaprax Instructions Guide here.

You can customize your 140x140 Wall Mounted Pergola with spans between 2.4-3.6m. Most common height for a Modaprax Pergola is 2.5m.

N.B. Allow for approx. 16cm additional span for the timber relative to shade sail. For example, if you choose a 2.84x2.84m shade sail, timber should be 3.0x3.0m. This gives you an 6-8cm spacing on each side after stretching the shade sail with the tension straps.

Our brackets are designed to seamlessly fit 90x90 timber - available in a premium dressed finish. Personalise your pergola by selecting from a variety of timber styles and lengths at your local timber warehouse.

Our brackets are designed for optimal fit with 140x140mm timber. To avoid shaving the timber, we have precision crafted their size and considered the clearance needed with the internal welding in the brackets.

Bracket Features:
Arm Opening Designed for 140x140mm timber fit
Arm Opening (Interior): 143 x 143mm
Arm Opening (Exterior): 149 x 149mm
Arm length: 230mm
Steel Thickness: 3mm Steel
Colour: Black (Powder Coated)
Six Fastening Holes: 7mm
Anchoring Holes: 12mm

Shade Sail Features
Synthetic high density polyethylene knitted fabric
Tension straps with buckles to tighten shade sail to Pergola Frame
Easy to connect and take down

Note: The polyethylene knitted fabric of the shade sail may seem smaller at first, but it's crafted for a snug fit, accommodating stretch over time for lasting flexibility in your pergola

A Note on Anchoring Hardware
Our kits come without the anchoring hardware as various flooring types (e.g. concrete, brick or timber decking) require different screws/bolts. The perfect anchoring hardware is easily accessible at your local hardware store who will advise you on selecting the ideal components.
